DuPont™ SFP-2880 UF Membrane: Advanced Water Purification for Industrial Applications

Detail produk:

Tempat asal:	CINA
Nama merek:	Dupont
Sertifikasi:	CE
Nomor model:	SFP-2880
Dokumen:	Model SFP-2860, SFD 2860, S...80.pdf

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 pc
Harga:	Dapat dinegosiasikan
Kemasan rincian:	Pengepakan Ekspor Standar
Waktu pengiriman:	5- 8 hari kerja
Syarat-syarat pembayaran:	Western Union, T/T.
Menyediakan kemampuan:	60000 unit per bulan

Kontak

Semua produk

Kotak Distribusi Pencahayaan (33)

Kotak Distribusi Listrik (33)

Kotak Distribusi Tahan Cuaca (48)

Kotak Kandang Fiberglass (60)

Sakelar Transfer Otomatis ATS (68)

Modul EDI (139)

Modul Membran Ultrafiltrasi (57)

Pemutus Sirkuit Industri (85)

sistem pv surya (72)

Stasiun Pengisian EV Listrik (21)

Relai Pengaturan Waktu Modular (12)

Relay Kontrol Otomatisasi (64)

Trafo Pengatur Tegangan (16)

Balon Penerangan Film (136)

Moon Balloon Light (131)

Balon LED Tripod (115)

Menara Cahaya Inflatable (62)

Aksesori Blok Terminal (6)

Detil Deskripsi produk

2880 rentang aliran modul:	3.1 - 9.3 m3 /jam	2880 Area Membran Modul:	77 m²
2880 Modul Diameter pori nominal:	0,03 μm	2880 Bahan Inti Modul:	Pvdf
2880 Modul Fluks Filtrat dari model ini:	40-120	Diameter model ini:	8 inci
Pengaturan Arah Aliran Produk:	Struktur tekanan eksternal, penyaringan jalan buntu	Produk Max. mengoperasikan TMP:	2.1 bar
Penggunaan:	Air permukaan, air laut, air minum	Adavantage:	Fluks besar

DuPont™ SFP-2880 UF Membrane: Advanced Water Purification for Industrial Applications

Product Overview

Engineered for excellence, the DuPont™ SFP-2880 ultrafiltration membrane represents cutting-edge water treatment technology. This premium-grade membrane utilizes state-of-the-art hollow fiber design to achieve exceptional filtration performance, effectively removing contaminants including pathogens, colloids, and particulate matter.

Specifically developed for demanding industrial environments, it serves as an ideal pretreatment solution for reverse osmosis systems and enables efficient wastewater recycling. The membrane demonstrates outstanding chemical compatibility and mechanical durability, ensuring stable operation under challenging conditions.

Key Features

Advanced Filtration Performance: Removes bacteria, viruses, and colloids with high efficiency; achieves filtrate turbidity below 0.1 NTU and SDI under 2.5; ideal protection for reverse osmosis systems
Engineered Durability: Chemical-resistant PVDF membrane withstands extreme pH conditions; U-PVC housing eliminates need for pressure vessels; operating temperature range supports global deployments
High-Efficiency Design: Industry-leading membrane area enables high flow rates; outside-in flow handles high solids loading; reduced backwash frequency lowers water consumption
Operational Reliability: Consistent performance in municipal and industrial settings; minimal maintenance requirements; compatible with automated control systems

Technical Specifications

Attribute	Value
UF Module Flux Range	40–90 LMH (24–53 gfd) at 25°C
Flow Rate per Module	2.0–6.9 m³/hr (8.8–30.4 gpm)
UF Module Temperature Limits	1–40°C (34–104°F)
UF Module Max Operating TMP	2.1 bar (30.5 psi)
Chemical Tolerance	Withstands up to 2,000 mg/L NaOCl
Membrane Area	77m²
Membrane Type	Industrial Grade Ultrafiltration Membrane Components

Product Specifications

Model	Type	Part #	Membrane Area (m²/ft²)	Volume (Liters/Gallons)	Weight (Kg/lbs)
SFP-2880	Pretreatment	280934	77 / 829	39 / 10.3	61 / 135 (empty), 100 / 220 (water filled)
SFD-2880	NSF/ANSI 61 Drinking water	324169	77 / 829	39 / 10.3	61 / 135 (empty), 100 / 220 (water filled)

Operating Parameters

Parameter	SI Units	US Units
Filtrate Flux @ 25ºC	40-120 l/m²/hr	24-70 gfd
Flow range	3.1-9.3 m³/hr	13.6 - 40.9 gpm
Temperature	1-40ºC	34-104ºF
Max. inlet module pressure (@ 20ºC)	6.25 bar	93.75 psi
Max. operating TMP	2.1 bar	30 psi
Max operating air scour flow	12 nm³/hr	7.1 scfm
Max backwash pressure	2.5 bar	36 psi
Operating pH	2-11

Important: If operating limits and guidelines given in this bulletin are not strictly followed, the limited warranty will be null and void. To prevent biological growth during system shutdowns, it is recommended that preservative solution be injected into the membrane modules.

Module Installation
