Name: Veolia E-Cell MK-3 MiniHT EDI module for pharmaceutical ultrapure water production
Brand: Wuxi Fenigal Science & Technology Co., Ltd.
SKU: MK-3MINIHT
Price: 4,899.20 USD
Availability: InStock

Wuxi Fenigal Science & Technology Co., Ltd

Produsen dan Pemasok Produk Industri & Pencahayaan

Indonesian

Rumah

Produk

Video

Tentang kita

Wisata pabrik

Kontrol kualitas

Hubungi kami

Rumah Produk Modul EDI

Veolia E-Cell MK-3 MiniHT EDI module for pharmaceutical ultrapure water production

Detail produk:

Tempat asal:	CINA
Nama merek:	VEOLIA
Sertifikasi:	CE
Nomor model:	MK-3MINIHT
Dokumen:	Veolia EDI catalog.pdf

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 pc
Harga:	Dapat dinegosiasikan
Kemasan rincian:	Pengepakan Ekspor Standar
Waktu pengiriman:	5- 8 hari kerja
Syarat-syarat pembayaran:	T/T, Western Union
Menyediakan kemampuan:	60000 unit per bulan

Kontak

Semua produk

Kotak Distribusi Pencahayaan (33)

Kotak Distribusi Listrik (33)

Kotak Distribusi Tahan Cuaca (48)

Kotak Kandang Fiberglass (60)

Sakelar Transfer Otomatis ATS (68)

Modul EDI (139)

Modul Membran Ultrafiltrasi (57)

Pemutus Sirkuit Industri (85)

sistem pv surya (72)

Stasiun Pengisian EV Listrik (21)

Relai Pengaturan Waktu Modular (12)

Relay Kontrol Otomatisasi (64)

Trafo Pengatur Tegangan (16)

Balon Penerangan Film (136)

Moon Balloon Light (131)

Balon LED Tripod (115)

Menara Cahaya Inflatable (62)

Aksesori Blok Terminal (6)

Detil Deskripsi produk

Kisaran laju aliran miniht dari mdoel ini:	0,5–1,6 m3 /jam (2,2-7,0 gpm)	Miniht pengiriman berat model ini:	57 kg (126 lbs)
Dimensi miniht dari model ini (lebar x tinggi x kedalaman):	30 cm x 61 cm x 29 cm	Resistivitas miniht:	≥ 10 (farmasi) atau ≥ 16 mohm-cm (industri
Sodium:	≤ 3 ppb (industri)	Suhu sanitasi maksimum:	85ºC (185ºF)
Tekanan saluran masuk sanitasi maksimum:	2.1 bar (30 psi)	Aplikasi:	Air murni farmasi

Veolia E-Cell MK-3 Mini HT EDI module for pharmaceutical ultrapure water production

Key Specifications

Flow Rate Range	0.5–1.6 m³/h (2.2–7.0 gpm)
Shipping Weight	57 kg (126 lbs)
Dimensions	30 cm x 61 cm x 29 cm
Resistivity	≥ 10 MOhm-cm (Pharmaceutical) or ≥ 16 MOhm-cm (Industrial)
Maximum Sanitization Temperature	85ºC (185ºF)

Advanced Technology Features

Patented HT-EDI™ technology for reagent-grade water production
90% lower energy consumption compared to mixed-bed systems
Maintenance-free operation with intelligent control system
Real-time monitoring of conductivity, pH, and pressure drop
Patented staggered flow channel design prevents scaling

Performance Advantages

Maintains resistivity above 18.2 MΩ*cm with 22% energy reduction compared to traditional EDI equipment. Achieves recovery rates exceeding 90% even with high-hardness raw water.

Available Configurations

Basic Unit - Standalone purification
RO-EDI Integrated - Complete purification skid
GMP Version - With full validation support

Quality Certifications

CE, RoHS, CSA and EAC marked
FDA-compliant materials
UKCA certified
Manufactured in ISO 9001 and ISO 14001 facility
Halal certified by IFANCA®

Technical Parameters

Parameter	Value
Inlet Pressure	6.9 bar (100 psi)
Max Temperature	40°C (104°F)
Pressure Drop	1.4-2.8 bar (20-40 psi)
Recovery Rate	Up to 93%
Conductivity	<117 µS/cm
pH Range	4-11

Applications

Ideal for water for injection, pharmaceutical purified water, and laboratory purified water systems. Complies with USP, EP, and other pharmacopeia standards.

Additional Resources

For more information about our EDI technology and application cases, visit FG Water Technologies.

About FG Water Technologies

FG Water Technologies is a high-tech entity specializing in water treatment equipment design, manufacturing, and international shipment. Our products serve various industries including pharmaceutical, food and beverage, chemical, and power.

Label:

Kontak Person: Mr. Harry

Tel: +86-13646187144

Produk lainnya

Veolia MK-3PharmHT Hot Water Sterilization EDI Module For Grade Ultrapure Water Preparation

EDI menumpuk resistivitas: ≥ 10 mohm-cm

Sodium Stack Edi: ≥ 99,9% Penghapusan

EDI Stack Silica (SiO2): Hingga 99% Penghapusan

Siklus Sanitasi Air Panas Tumpukan EDI: 160

Veolia E-Cell MK-3 EDI Stack for Continuous High-Purity Water Production

Produksi air maksimum standar (M3 /jam): 4.5

Produksi air minimum standar (M3 /jam): 1.6

Pemulihan Standar: Hingga 96%

Berat pengiriman standar tumpukan ini: 100 kg (220 lbs)

Veolia MK-5 EDI Module (Previously E-CELL-3X) For Semiconductor Industries

Perbedaan tekanan minimum MK-5 antara outlet encer dan inlet konsentrat (batang): 0.34

MK-5 Inlet/Outlet Standard Pressure Drop (BAR): 1.4-2.8

Tekanan saluran masuk MK-5 (batang): Counter-Current: 4.1-6.9 CO-CURRENT: 3.1-6.9

MK-5 Amperage (ADC): 0-5.2

Veolia E-Cell MK-9 EDI Module For High-Flow And Robust Design

Dimensi tumpukan MK-9 (cm sebagai lebar x tinggi x kedalaman): 30 x 61 x 74

MK-9 Total Anion yang dapat ditukar (ppm sebagai CaCO3): <13

Konduktivitas tumpukan MK-9 (μs/cm): <22

MK-9 Stack PH: 4-11

Ionpure LX-Z IP-LXM45Z-5 CEDI Module: Chemical-Free High-Purity Water System for Industry

45Z-5 Tumpukan Laju Aliran Minimum M3/HR (GPM): 2.57 (11.3)

45Z-5 Stack Design Flow Rate M3/HR (GPM): 5.1-7.67 (22.5-33.8)

45Z-5 Stack pengiriman berat kg (lbs): 205 (451)

45Z-5 Stack Operasi Berat Kg (lbs): 157 (345)
